Our stacking pin measures 1.25″ outer diameter on either end and 9″ long. Each end has a hole for pinning to the frame both on the top and the bottom. The scaffold pin has a 1″ collar in the middle, and the collar is brad installed. The ends are tapered for an easy fit, and these stack pins are galvanized for longevity.
Stack Pin – 1.25″ OD (#5)
SKU: 381SP1.25
Included:
- (1) Scaffolding Stack Pin – 1.25″ OD (#5)
Spring rivet not Included, typical use requires one spring rivet per stack pin.
Use exclusively with 1.25″ OD (#5) tube scaffold frames.
$2.39
| Weight | 0.90625 lbs |
|---|---|
| Length | 9" |
| Height | 1.75" |
| Width | 1.75" |
| Collar Length | 1" |
| Outside Diameter | 1.25" |
| Center of Hole to Center of Hole | 6" |
| UPC | 850009279934 |
